Lehmann Linear Headphone Amplifier - A high quality headphone amplifier is as important for listening to music with a pair of headphones as are stable power amplifiers for the loud-speakers of your stereo setup. Dynamic headphones are far more different than most people realize. For the same sound pressure level the power needed with different headphone models can vary up to a factor of about 500! Impedances can be different to a factor of more than 20!
This is the reason why different headphone models have very individual requirements to the headphone amplifier driving them in terms of voltage and current. Everybody who once has connected a high quality headphone to any given standard headphone output knows about this problem.
With the launch of the Black Cube Linear there is now a high end headphone amplifier to realize even the highest demands to reference quality headphone music reproduction.
The selectable gain (0dB, 10dB, 20dB) of the Black Cube Linear effectively optimizes the output level of the zero global feedback Class A output stage. Practically all high quality dynamic headphones available will show their best possible performance, no matter if you have an easy to drive low impedance pair of headphones or an ineffective pair of 600 Ohms studio cans.
Carefully selected top notch components and a highly sophisticated circuit design guarantee top notch listening pleasure. Now you can hear that ultra transparent sound and the explosive dynamics formerly known only from electrostatic headphones. An overdimensioned power supply with a huge magnetically and statically shielded toroidal transformer is included internally allowing a power cable of your choice to be directly connected to the unit.
For stereo setups with just one source like a CD player or a turntable with a phono stage the Black Cube Linear is the simplest and most effective active preamp one can think of. All audio connectors including the two Neutrik phone jacks come with gold plated contacts. No external Y-adapter is needed!
The faceplate and the massive milled aluminum knob for the smooth running 27mm ALPS high grade volume control are available in anodized black or silver.
To to get the best out of your headphone you will have to try the Black Cube Linear.
|Maximum Gain:||0dB, 10dB, 20dB (Switchable)|
|Frequency Response:||10Hz (-0.3dB) to 35kHz (-1dB)|
|Signal-to-Noise:||>95dB at 0dB Gain|
|THD:||<0.001% at 6mW/300O|
|Channel Separation:||>70dB / 10kHz|
|Output Power:||200mW / 300O |
400mW / 60O
|Output Impedance:||Line-Out: 60O|
|Power Dissipation:||<5W, Internal, Regulated Power Supply|
|Dimensions:||280 x 110 x 44m³ (Case Only)|
|Connectors (Audio):||Neutrik Phone Jacks (6.35mm)|
1 x Parallel to Line-Out
1 x Line-Out Muting
Gold-Plated Connectors With Teflon Isolation
