Lehmann Rhinelander Headphone Amplifier

Lehmann Rhinelander Silver

Swipe the images above to see more shots

(based on 0 review(s))

Click here to write a review

Price: £315.00 Was £335.00

Please select your options and then add to basket



The popular Lehmann Rhinelander headphone amplifier is based on the legendary Black Cube Linear by Lehmann audio, which is used by well-known industry professionals such as A.J. van den Hul, Andreas Spreer (TACET) and Maarten de Boer (The Masters). Now you can experience a huge part of the Linear's transparency, tonal balance and micro-detail, and at only a fraction of the cost. The Rhinelander is placed in the highly-competitive sector of ambitioned, budget-conscious, audiophile listeners.

Moreover, with some mild tweaks the Rhinelander can also be used as a single source pre-amplifier, like the superior Linear model. The Rhinelander is equipped with two inputs and a relays source selection. If you don't need the second line input, you can reconfigure the input jack to a output. All you need to do is to replace two jumpers.

Even with entry-level devices, Lehmannaudio puts a lot of effort into details.

Key Features:

  • Discrete Zero Global Feedback output stage with high quiescent current ready to drive most headphones or long cable runs
  • Audiophile voltage amplifier stage
  • Single source preamplifier reconfigurable to "headphone only" mode with two line source inputs by replacing just two jumpers
  • Relays source selection / mute operation
  • Only MKP caps in the signal path for perfect transient response and ambience reproduction
  • Gain jumper selectable 6dB/20dB
  • Hand selected potentiometer with very good channel tracking
  • Double sided audio board
  • External AC power supply
  • Ultra fast rectifying diodes
  • We only use low ESR electrolytic caps
  • Low-noise, regulated power supply
  • Gold plated RCA connectors
  • Original Neutrik headphone jack with gold plated contacts
  • Anodized aluminium faceplate and knob

Specifications:

Input Impedance:47kO
Maximum Gain:6dB, 200dB
            (Jumper Selectable Inside)
Frequency Response:10Hz (-0.3dB) - 35kHz (-1dB)
Signal-to-Noise Ratio:>95dB at 0dB Gain
Channel Separation:>70dB / 10kHz
Output Power:120mW
Output Impedance:50O
Power Consumption:Appx. 3W, Via External A/C PSU
Audio Connectors:Neutrik Headphone Jack 1/4" Plug
            RCA Jacks With Gold Plates Contacts
            Line Output Is Muted When Headphones In Use
Face Plate:Andozied Aluminium, Black or Silver
