Over the past 45 years, Mission has become famed for loudspeakers that break the norms of price-point, technology and design. Yet, in its illustrious history, Mission was also responsible for some equally prolific hi-fi electronics.

Thus, the Digital Mission 778X is a revisit of a classic Mission amplifier concept that was the Mission 778 – an affordable integrated amplifier that offered simplicity in operation but over-performed in the driving of loudspeakers.

Today’s Mission 778X maintains the influence of simplistic operation, large tractile controls and a multitude of inputs including AptX Bluetooth and Digital, It’s a compact, ’80s inspired integrated amplifier that is fully equipped to meet the demands of modern music lovers, from vinyl fans to digital streamers. Modern twists, such as LED level indicators and all-encompassing connectivity options, make the 778X a truly contemporary integrated amplifier with 2 x 45 watts (8 ohms) of power via an utterly modern and refined signal path, to standards akin to the exemplary standards to which Mission loudspeakers are developed

General Description Stereo Digital Amplifier

Design Philosophy and Core Technology • Integrated Amplifier (45 watts @8 ohms, 65 watts @4 ohms)

• ESS Sabre32 ES9018K2M Reference Chip

• Ultra-low Noise Digital Audio File Compability (384kHz PCM, DSD256) • Bluetooth 5.0 (aptX / AAC) Support

• Dedicated High-performance, Low-noise MM Phono Stage

• Headphone AMP With High-speed Output Signal Transition

• USB Upgrade Support

• Large Tractile Controls With LED Level Indicators

Inputs 1 x Coaxial, 2 x Toslink Optical, 1 x PC USB, 1 x AptX/AAC Bluetooth,

2 x AUX,1 x RCA (Phono MM)

Outputs 1 x Coaxial, 1 x Toslink Optical, 1 x RCA (PRE Out)

Sampling Frequency Optical / Coaxial: 44.1kHz-192kHz;

PC USB:44.1kHz-384kHz(PCM) / DSD64, DSD128, DSD256

Preamplifier Section

Gain (max.) +0dB (Line), +47dB (Phono MM)

Input Sensitivity 540mV (Line, Volume = 0dB); 2.5mV (Phone MM, Volume = 0dB)

Input Impedance 10K (AUX); 47K//100pF (Phono MM)

Total Harmonic Distortion (THD) <0.003%

Frequency Response (ref. 1kHz) 20Hz-20kHz (±0.1dB)

PRE Output Level 2.1Vrms (max.)

PRE Output SNR >110dB (A-weighted)

Digital to Analogue Converter

D to A Converter ESS Sabre32 ES9018K2M

Resolution 32-bit

Max. Sampling Frequency Optical/Coaxial: 192kHz;

USB: PCM 384kHz / 11.2896MHz (DSD256)

Total Harmonic Distortion (THD) < 0.001% (1KHz @ 0dBFS)

Output level (0dBFS, 1KHz) 2.1Vrms

Power Amplifier Section

Gain +31dB

Rated Power Output 2 x 45W (@ 8ohms); 2 x 65W (@ 4 ohms)

Frequency Response (ref. 1kHz) 20Hz-20KHz (± 0.5dB)

Total Harmonic Distortion (THD) <0.005% (30W / 8 ohms)

Input Sensitivity 540mV (RCA AUX In); 2.5mV (Phono MM)

Signal-to-Noise Ratio (SNR) >108dB (ref. 45W, A-weighted)

Crosstalk @1K >80dB (ref.1W)

Standby Power Consumption <0.5W

Headphone Amplifier

Total Harmonic Distortion (THD) < 0.01% (1kHz, 50mW )

Output Impedance 4.7 ohms

Load impedance 20-600 ohms

General

Dimensions (mm) (W x H x D) 236x98x380.6

Carton Size (mm) ( W X H X D) 450x392x175

Net Weight 6.3kg

Finish Black / Silver

Power requirements (depending on region) 220-240V ~ 50/60Hz; 100-120V ~ 50/60Hz

Standard Accessories Power Cord, Remote Control, User Manual, Antenna
