The Arcam AVR11 brings sensational realism to your ears with native 12-channel decoding from Dolby Atmos and DTS:X. This AV receiver gives you the full theatre experience in your own home. AVR11 also supports Apple ®Airplay2, Google Chromecast ®, Bluetooth with aptX ®HD, Spotify Connect, Tidal Connect and UPnP with the MusicLife app.
Rich Musicality + Immersive Sound = Stunning Realism
The AVR11 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With native 12-channel decoding of immersive audio from Dolby Atmos and DTS:X, the AVR11 can deliver incredible theatre experiences.
The Arcam AVR11 is designed with a passion for music and movies, bringing both to life with truly high fidelity. The AVR11 features an over-engineered power supply and transformer for real world power with low noise. The 7 channels of Class AB amplification
are based upon those in Arcam stereo amplifiers, guaranteeing musicality otherwise not heard from other AV receivers.
The performance and musicality can be assured with Dirac Live® room optimisation included, and accessed instantly with integrated streaming using Apple ®Airplay2, Google Chromecast ®, Bluetooth with aptX ®HD, Spotify Connect, Tidal Connect and UPnP with the MusicLife app.
Dolby Atmos, DTS:X & AURO-3D 7.1.4 decoding
7 HDMI inputs, 2 HDMI outputs, eARC compatible
HDMI 2.1 with HDCP2.3
All inputs support 8K@60fps and 4K@120fps
Supports Dolby Vision, HDR10+, HDR10 and HLG
Includes Dirac Live® room correction
Ready for Dirac Live Bass Control
Dual ESS 9026PRO audiophile DACs with ESS reference voltage regulators
7 Channels of Class AB power amplification
Wi-Fi / Ethernet, RS232 and IR control
Google Chromecast® built-in for streaming audio
Free MusicLife iOS and Android UPnP app
CONTINUOUS POWER OUTPUT, PER CHANNEL, 8?/4?
2 channels driven, 20Hz - 20kHz, <0.02% THD 80W/100W
2 channels driven, 1kHz, 0.2% THD 85W/120W
7 channels driven, 1kHz, 0.2% THD 60W/85W
Residual noise & hum (A-wtd) <0.15mV
STEREO LINE INPUTS
Maximum input 4.5V rms
Nominal sensitivity 1V, 2V, 4V (user adjustable)
Input impedance 47k?
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct 100dB/110dB
Frequency response 20Hz—20kHz ± 0.2dB
Nominal output level 1V RMS (max. 5V RMS)
Output impedance 560?
THD+N (20Hz—20kHz) –100dB
Maximum output level into 32? 5Vrms
Output impedance <100?
Mains voltage 110–120V or 220–240V, 50–60Hz
Power consumption (maximum) 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical) 100W (Thermal dissipation approx. 340 BTU/hour
Power consumption (standby) <0.5W
Dimensions W x D (including speaker terminals) x H (including feet) 433mm x 425mm x 171mm
Weight (net) 16.5kg
Weight (packed) 19.8kg
Supplied accessories Mains lead
Remote control with 2 x AAA batteries
3 x WiFi/Bluetooth antennas
