Arcam R Series rPhono MM / MC RIAA Phono PreAmplifier. Available with Online Finance and Free Delivery.
Designed specifically to replace an in-built phono amplifier or to add a turntable connection to your existing amplifier, the rPhono is the latest addition to the rSeries.
The rPhono benefits from Arcam’s more than forty years of analogue audio expertise and uses the finest quality parts in a layout that is optimised for low noise and minimum distortion. The multi-layer PCB allows our designers to maximise the quality of the ground plane so that interference between components is further reduced. The use of multiple, low-noise, individually regulated power supplies ensures the rPhono delivers the cleanest signal to the audiophile quality output stage.
Featuring a wealth of features specifically designed for optimal matching of your turntable’s cartridge, the rPhono is the perfect solution for the vinyl lover. Moving coil users benefit from precision impedance matching using high-quality trimmers instead of discrete steps, while moving magnet users have a wide variety of capacitance options. An optionally selectable low frequency “rumble” filter eliminates the effects of warping or pressing irregularities, which can be present on some vinyl.
Precision components give excellent RIAA response and classleading performance figures, meaning the rPhono will delight all music-lovers.
The rPhono is a simple way to improve the performance regardless of turntable and brings Arcam quality sound to any system.
• Moving coil & Moving magnet support
• Adjustable input impedance 50-550O (MC)
• Adjustable input capacitance (MM)
• Rumble filter
• Precision RIAA filter response
• High-end audio circuitry
• Stylish cast aluminium case
Frequency response, Rumble filter OFF
20Hz-50kHz +/-0.2dB, -3dB at 7Hz
Frequency response, Rumble filter ON
45Hz-50kHz +/-0.2dB, -3dB at 20Hz, -13dB at 10Hz
THD+N (at 1kHz, 5V Out), MC input, 30dB gain
THD+N (at 1kHz, 5V Out), MM input, 30dB gain
System gain, MC input
60, 70, 80, or 82dB
System gain, MM input
30, 40, 50, or 52dB
Input impedance, MC input
50-550O + 1nF
Input impedance, MM input
47kO + 120, 220, 340 or 440pF
Equivalent noise (A-wgt, 40dB MM gain), MC input
Equivalent noise (A-wgt, 40dB MM gain), MM input
Output level, Nominal
Output level, Maximum
Power requirements (max)
12V DC, 2.0A
194 x 44 x 124mm
Power supply with interchangeable plugs
Stereo phono-phono cable
DIP switch and pot trim tool
User manual and registration card
