The JBL SA750 is a high-output class G integrated amplifier that is released to celebrate JBL’s 75th Anniversary. The retro-inspired SA750 is a mix of today's modern technology with JBL's classic acoustic design. It’s a perfect counterpart to your JBL L100 75 speaker pair.
The front panel has a volume, balance and input dials with solid switches for power, mute, direct, MC/MM phono, and Dirac Live room calibration. It also includes a 3.5mm Aux input and 3.5mm Headphones output, and a 2-line orange display screen.
The SA750 is a high-performance Class G amplifier that is designed to deliver 120W of power per channel into 8Ω, and 220W per channel into 4Ω. This is to provide intricate details of audio, accuracy at low levels, a low crossover distortion, and a high-current capability for high power demands - this is a great counter part for your L100 Classics.
The SA750 has built-in streaming capabilities that include Google Chromecast and Apple Airplay 2 so you can stream from over 300+ services. It also features a high-resolution DAC, a switchable MM/MC phono input that is perfect for vinyl lovers, support for UPnP wireless, full MQA file decoding and Dirac Live, which is a highly accurate room calibration system for improved audio performance in any listening room.
It also has Ethernet and WiFi with UPnP for connecting to a home network, USB connection, Ethernet and RS-232 serial control for third-party control systems, two optical and two coaxial digital inputs, and six pairs of analogue RCA inputs.
Frequency Response 20Hz – 20kHz ± 1dB
Nominal Sensitivity 1V
Input Impedance 10kΩ
Power output both channels driven 120W into 8Ω, 220W into 4Ω
Maximum Input 6Vrms
Total harmonic distortion + noise 0.002%
Signal/Noise ratio (A-wtd) 50W, ref. 1V input 120dB
Mains Voltage 110-120V or 220-240V, 50-60Hz
Maximum Power Consumption 800W
Product Dimensions (WxHxD, including feet, control knob, and speaker terminals) 449 x 114 x 327mm
Product Weight 12kg
Shipping Weight 14kg
Warranty 5 Years
