The Monitor Audio Silver FX-7G effects speakers have had a significant aesthetic upgrade, the updated design forgoes the previous designs grille pegs and now has a magnetic grille for the very first time on the Silver FX line. The model has been enhanced with the silver series 7G drivers and crossover design. The FX 7G now offers an excellent rear channel option, perfect for home cinema setups.
An upgraded Cone profile provides a more sturdy profile and features an evolved hexagonal, dimpled structure taken from the Platinum II Series’ RDT II Driver development. Designed to give a look at the internal design elements which are not usually visible.
Monitor Audio have created an updated mid-range following the same design aims as the Gold 5G; to improve directivity via a compact design and to maximise the driver bandwidth, allowing for a smooth crossover with the tweeter.
The Silver FX 7G cone & surround geometry is enhanced together to dampen the main cones resonance, influenced by the Bronze 6G development and paired with the Uniform Dispersion Waveguide results in a far higher performance from the full setup. The silver FX 7G voice coil diameter has been increased from 25mm in the Silver 6G to 28.5mm in the Silver 7G.
The crossover separates the signals between tweeter and bass drivers in the Silver FX 7G, making the design crucial to the overall speaker performance. Silver 7G instruments a combination of third-order filters for all tweeter sections with a combination of second and third on the bass and midrange drivers
The Monitor Audio Silver FX 7G features a fresh look that comes in two finishes available to order; Satin White and High Gloss Black. The tweeter trims now match the cabinet finish, the protection dispersion pattern has been upgraded and is made from durable, stainless steel.
System Format 2 way Dipole / Bipole
Frequency Response 81 Hz 35 kHz
Sensitivity (2.83v @ 1m) 87.5 dB
Nominal Impedance 8 Ohms
Minimum Impedance 4.1 Ohms @ 240 Hz
Maximum SPL 104 dB
Power Handling (RMS) 85 W
Recommended Amplifier Requirements 30 85 W
Crossover Frequency 2 kHz
Port Tuning Frequency N/A
Bass Alignment Sealed cabinet
Drive Unit Complement 1 x 6" RST II bass/mid driver 2 x 1" (25 mm) gold dome C-CAM tweeter with UD waveguide
External Dimensions (Including Grille and Terminals (H x W x D)) 250 x 312 x 147 mm (913/16 x 135/64 x 513/16")
External Dimensions (including Outrigger Feet and Spikes (H x W x D)) N/A
Weight (each) 4.5 kg (9 lb 15 oz)
