The Encore Connect is an audio pre amplifier/source component allowing you to keep all your music in one place. It accepts almost any conceivable analog or digital audio source. It is also compatible with many network speakers, such as Sonos. It features a very clear, large, high-resolution full colour display so you can see what’s going on.
Inputs: | 3x line level RCA 300mV nominal 2V typical up to 7V rms 2x optical S/PDIF 24 bit inputs up to 192kHz 2x coax S/PDIF 24 bit inputs up to 192kHz 1x USB 3.0 type 'A' connector 1x USB 3.0 type 'B' connector (for future expansion) 3x USB 2.0 type 'A' connector (1 front, 2 rear) 10/100/1000 Base-T Ethernet connector |
Output: | 1x line level Pre-Amp variable outputs (.6V rms max) 1x line level fixed 2.0V @ 0dBFS (300mV rms nominal, >6V rms max) Preamp gain, line input to Pre-Amp output 4.5x (13dB) at max volume Headphone output suitable for headphones impedance 8Ω to ∞ Headphone output features independant volume setting 1x optical S/PDIF 24-bit output up to 192kHz 1x coax S/PDIF 24-bit output to 192kHz Internal storage 2.5" 2 TB SATA II hard disk (included) or SSD (future upgradable) |
Dimensions: | Width: 440mm Height: 125mm Depth: 400mm |
Weight: | 18kg |
