The M6 SDAC is a very high-quality DAC. It has 7 inputs: 3 x Coax, 3 x Optical and 1 x USB and will accept all data rates up to 32bit 768kHz and DSD 64/128. The M6SDAC has incredibly low distortion, stereo separation is better than 120dB, Noise ratio is better than 119dB down and Linearity is better than 110dB. It excels in every technical area.

The M6SDAC's immediate sonic impression is of effortless grace and transparency, there is a sensation of communication from the artists that is hypnotic and compelling. It is so musically integrated: the whole sound is sweet and clear; the treble is completely grain free and extended.  The bottom end sounds endless with tactile bass dynamics and light speed fast attack/decay. The imaging, as you would expect from better than 120dB separation, is excellent: side to side, image placement, a palpable sense of the recording venue that places the performers in real-time holographic space.

Key Features:

  • 32bit 768kHz
  • True Upsampling/Reclocking DAC with DSD
  • 7 Inputs
  • Very High Performance Headphone Amp
  • Single Ended and Balanced Fixed/Variable Outputs
  • Top quality over sampling 32 bit sample rate converter circuit

Technical Data

Output (RCA/XLR): Output Impedance: 47Ω
RCA Output: 2.2V R.M.S nominal (RCA) 4.4 R.M.S (XLR)
Headphones: Power: 1.5W / channel into 32Ω
Output devices: 2 per channel
Output impedance: 40Ω Suitable for 10-600Ω headphones
THD: <0.005% typical 20Hz to 20kHz
Signal/noise ratio: >115dB "A"-wtd
Total harmonic distortion: <0.0012% 10Hz to 20kHz
DAC: DAC Circuit: 32 bit Hyperstream II
Total correlated jitter: <12 picoseconds peak to peak
Linearity: <±0.1dB down to -96dB
Frequency response: <2Hz to 90kHz typically, -3dB (192 kHz input sample rate)
Channel seperation: >105dB 02Hz to 20kHz
Signal to noise: >120dB "A"-wtd
Total harmonic distortion: <0.0012% 10Hz to 20kHz
Line level outputs: 1 pair line level RCA (phono), left and right
1 pair line level XLR (balanced), left and right
Digital inputs: 3x RCA coaxial SPDIF in, 32-192kbps (16-24 bit stereo PCM)
3x TOSLINK optical in, 32-192 kbps (16-24 bit stereo PCM)
1USB 2.0in, type 'Micro B' connector for computer/PDA/other "host"
16-32 bits, 32-192 kbps fully asynchronous
(actual data determined by source filme/computer software settings)
Mains voltages: 230V/115V internally set or 100V optional
Consumption: 20Watts maximum
Dimensions: Width: 440mm
Height: 100mm
Depth: 380mm
Weight: 6.9kg (unboxed)

Musical Fidelity M6s DAC

£1,399.00

  Finance From £37.18 a month

  Delivery Standard Shipping and Click & Collect

  Payment Secure payment available
