Pathos AmpliD Power Amplifier

Swipe To Cycle Images

Pathos Ampli D Power Amplifier. Available with Online Finance and Free Delivery

AmpliD is the first of a new line of digital amplifiers from Pathos. Completely balanced in D Class, it features a 70 Watt output power on each channel at 8 Ohm, and 130 Watt on each channel at 4 Ohm; it has 2 kinds of inputs (1 as stereo balanced XLR and 1 as stereo unbalanced RCA line).

Despite small dimensions, AmpliD provides great power and high sound quality. It reached state-of-the art among all those digital amplifiers, that cannot be underestimated in terms of technological innovation.

Aluminum has been used both for panting and for frame, on the upper part can be found our carved logo. High quality components and superior technology allow this product to stand any comparison with the products of its category.

AmpliD is available in two finishes and, if combined with Converto EVO and In The Groove, will set up a perfect audio system both for digital and phono source.
This product is entirely handmade in Italy.

SPECIFICATIONS

Type Stereo power amplifier in pure class D, fully balanced
Output Power 70W @ 8 Ohm  130W @ 4 Ohm
Frequency response 1 Hz – 100 KHz
THD < 0,04%
Dumping factor 50
S/N Ratio 98 dB
Input impedance 47 KOhm
Analogue inputs 1 stereo balanced XLR & 3 stereo unbalanced RCA line
Input sensitivity 0,8 VRMS Unbalanced  0,8+0,8 VRMS Balanced
Output impedance 0,16 Ohm
Gain 29 dB Unbalanced  23 dB Balanced
Power consumption min 8W   Max 300W  <0,5W standby mode
Size 230mm (D) x 200mm (W) x 70mm (H)
Weight (net/packed) 5 Kg /6Kg

£1,049.00
0% Finance Available

Free UK Delivery

Secure Payment
